第8章 RIPng

8.1 RIPng配置

1.R1配置ipv6地址

[R1]ipv6
[R1]interface GigabitEthernet 0/0/0
[R1-GigabitEthernet0/0/0]ipv6 enable
[R1-GigabitEthernet0/0/0]ipv6 address 2012::1
[R1]interface GigabitEthernet 0/0/1
[R1-GigabitEthernet0/0/1]ipv6 enable
[R1-GigabitEthernet0/0/1]ipv6 address 2001::1 64

2.R2配置ipv6地址

[R2]ipv6
[R2]interface GigabitEthernet 0/0/0
[R2-GigabitEthernet0/0/0]ipv6 enable
[R2-GigabitEthernet0/0/0]ipv6 address 2012::2 64
[R2]interface GigabitEthernet 0/0/1
[R2-GigabitEthernet0/0/1]ipv6 enable
[R2-GigabitEthernet0/0/1]ipv6 address 2023::2 64

3.R3配置ipv6地址

[R3]ipv6
[R3]interface GigabitEthernet 0/0/0
[R3-GigabitEthernet0/0/0]ipv6 enable
[R3-GigabitEthernet0/0/0]ipv6 address 2002::3 64
[R3]interface GigabitEthernet 0/0/1
[R3-GigabitEthernet0/0/1]ipv6 enable
[R3-GigabitEthernet0/0/1]ipv6 address 2023::3 64
[R3]interface GigabitEthernet 0/0/2
[R3-GigabitEthernet0/0/2]ipv6 enable
[R3-GigabitEthernet0/0/2]ipv6 address 2003::3 64

4.R1配置RIPng

[R1]ripng 1
[R1]interface GigabitEthernet 0/0/0
[R1-GigabitEthernet0/0/0]ripng 1 enable
[R1]interface GigabitEthernet 0/0/1
[R1-GigabitEthernet0/0/1]ripng 1 enable

5.R2配置RIPng

[R2]ripng
[R2]interface GigabitEthernet 0/0/0
[R2-GigabitEthernet0/0/0]ripng 1 enable
[R2]interface GigabitEthernet 0/0/1
[R2-GigabitEthernet0/0/1]ripng 1 enable

6.R3配置RIPng

[R3]ripng
[R3]interface GigabitEthernet 0/0/0
[R3-GigabitEthernet0/0/0]ripng  1 enable
[R3]interface GigabitEthernet 0/0/1
[R3-GigabitEthernet0/0/1]ripng 1 enable
[R3]interface GigabitEthernet 0/0/2
[R3-GigabitEthernet0/0/2]ripng 1 enable

7.R1查看RIPng路由表

[R1]display ripng 1 route
   Route Flags: R - RIPng
                A - Aging, G - Garbage-collect
 Peer FE80::2E0:FCFF:FEBD:253A on GigabitEthernet0/0/0
 Dest 2002::/64,
     via FE80::2E0:FCFF:FEBD:253A, cost  2, tag 0, RA, 6 Sec
 Dest 2003::/64,
     via FE80::2E0:FCFF:FEBD:253A, cost  2, tag 0, RA, 6 Sec
 Dest 2023::/64,
     via FE80::2E0:FCFF:FEBD:253A, cost  1, tag 0, RA, 6 Sec

8.R2查看RIPng路由表

<R2>display ripng 1 route
   Route Flags: R - RIPng
                A - Aging, G - Garbage-collect
 Peer FE80::2E0:FCFF:FECB:6397 on GigabitEthernet0/0/0
 Dest 2001::/64,
     via FE80::2E0:FCFF:FECB:6397, cost  1, tag 0, RA, 29 Sec
 Peer FE80::2E0:FCFF:FEDC:49D7 on GigabitEthernet0/0/1
 Dest 2002::/64,
     via FE80::2E0:FCFF:FEDC:49D7, cost  1, tag 0, RA, 17 Sec
 Dest 2003::/64,
     via FE80::2E0:FCFF:FEDC:49D7, cost  1, tag 0, RA, 17 Sec

9.R3查看RIPng路由表

<R3>display ripng 1 route
   Route Flags: R - RIPng
                A - Aging, G - Garbage-collect
 Peer FE80::2E0:FCFF:FEBD:253B on GigabitEthernet0/0/1
 Dest 2012::/64,
     via FE80::2E0:FCFF:FEBD:253B, cost  1, tag 0, RA, 12 Sec
 Dest 2001::/64,
     via FE80::2E0:FCFF:FEBD:253B, cost  2, tag 0, RA, 12 Sec

10.R2配置路由过滤

[R2]acl ipv6 number 2000
[R2-acl6-basic-2000]rule deny source 2003:: 64
[R2-acl6-basic-2000]rule permit
[R2]ripng 1
[R2-ripng-1]filter-policy 2000 import

 11.验证结果

<R1>display ripng 1 route
   Route Flags: R - RIPng
                A - Aging, G - Garbage-collect
  Peer FE80::2E0:FCFF:FEBD:253A on GigabitEthernet0/0/0
 Dest 2002::/64,
     via FE80::2E0:FCFF:FEBD:253A, cost  2, tag 0, RA, 24 Sec
 Dest 2023::/64,
     via FE80::2E0:FCFF:FEBD:253A, cost  1, tag 0, RA, 24 Sec

[R2]display ripng 1 route
   Route Flags: R - RIPng
                A - Aging, G - Garbage-collect
 Peer FE80::2E0:FCFF:FECB:6397 on GigabitEthernet0/0/0
 Dest 2001::/64,
     via FE80::2E0:FCFF:FECB:6397, cost  1, tag 0, RA, 23 Sec
 Peer FE80::2E0:FCFF:FEDC:49D7 on GigabitEthernet0/0/1
 Dest 2002::/64,
     via FE80::2E0:FCFF:FEDC:49D7, cost  1, tag 0, RA, 27 Sec
