1.R3配置RIPv1
[R3]rip 1
[R3-rip-1]version 1
2.查看R2配置RIP路由,无R3路由
[R2]display ip routing-table protocol rip
Destination/Mask Proto Pre Cost Flags NextHop Interface
1.1.1.0/24 RIP 100 1 D 12.1.1.1 GigabitEthernet0/0/0
1.1.2.0/24 RIP 100 1 D 12.1.1.1 GigabitEthernet0/0/0
1.1.3.0/24 RIP 100 1 D 12.1.1.1 GigabitEthernet0/0/0
[R2]display ip routing-table protocol rip
3.R2配置RIPv1路由,查看RIP路由表
[R2]rip 1
[R2-rip-1]version 1
[R2]display ip routing-table protocol rip
3.0.0.0/8 RIP 100 1 D 23.1.1.3 GigabitEthernet0/0/1
